    Through Way Type PN25 DN25 Cryogenic Ball Valve For LN2

    Ask Lasest Price
    Brand Name : OEM
    Model Number : OEM
    Certification : CE/ISO
    Price : USD268 per pc
    Payment Terms : T/T
    Supply Ability : 3000pcs per month
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    Through Way Type PN25 DN25 Cryogenic Ball Valve For LN2

    Flange Type PN25 DN25 Cryogenic Ball Valve for LO2 LNG

    Applications
    Liquefied natural gas (LNG)
    Liquefied petroleum gas (LPG)
    Liquefied oxygen
    Liquefied hydrogen.
    Air separation industry
    Design Features & Benefits
    Extended bonnet design to ensure reliability of the stem packing & sealing.
    Drainage board design to prevent condensation water.
    Anti-Statistic & Fire-safe Design.
    Cavity automatic self pressure relief, suitable and safe for explosive medium.
    Live-load API 622 certified graphite and lip-seal sealing to ensure API 624 fugitive emission compliance.
    Suitable for working temperature as low as -196℃ .
    Multiple Seat Design option, suitable for various working medium and condition.
    Top Entry or Side Entry optional design.

    Product Description


    Valve Type:Falange Type Ball Valve
    Operated Type:Handwheel
    Connection Type:Flange
    Structure Type:Through Way Type
    Nominal Diameter:DN10~100mm
    Nominal Pressure:PN4.0MPa, PN2.5MPa
    CL300
    Material:Valve Body:ZGOCr18Ni9
    Valve Bonnet:OCr18Ni9
    Valve Stem:OCr18Ni9
    Stuffing:PTFE
    Disc seal ring:PCTFE
    Suitable Medium:LO2,LN2,LAr,LNG,etc
    Suitable Temparature:(-196℃~+80℃)
    Design and Manufacture:Conform to GB/T24925-2010
    Testing:Conform to GB/T13927-2008
    Valve Lifetime:Specified according to usage frequency and installation location
    Lead Time:

    Customized valves are usually 30~45 days;

    Stock valves are usually within 5 days.


    Customer Notice

    For your company to order valve products in our company, our factory makes the following commitments in terms of after-sales service:


    1. Our company implements warranty on product quality;


    2. After the contract is signed, guarantee the quality and quantity, and deliver on time;


    3. The company ensures that the valve products provided meet the contract targets


    4. For technical consultation of the demand side, give answers at any time;


    5. When delivering the equipment, the factory delivers the following materials to the purchaser: delivery list, product certificate, product sample, product instruction manual, technical information;

    After receiving a letter or a phone call from the user regarding quality issues, we guarantee a response within 24 hours to resolve the issue as quickly as possible


    Our Product


    OUR ADVANTAGE

    1. Excellent technology:

    the technology is in the leading level in China, cooperate with the most famous

    universities in China;


    2. Advanced equipment:

    advanced processing equipment and testing means, providing the integration of automation system solutions for product, engineering, service and training.


    3. Strong team:

    have many senior engineers with plenty of research, development, design

    experience, providing professional service for sales and after sales.


    4. Good quality:

    reliable and stable quality, good performance, long life time.


    5. Full series of products:

    covers full category of valves, meet the general standard of every country in the world, such as GB, DIN, ASTM, BS, JIS.


    6. Professional after sales service:

    have the professional engineer team to provide the service.


    7. Certificates:

    passed the ISO9001 certificate as well as CE,ISOetc.


    8. Fast delivery time:

    have the stock, fast delivery time could be guarantee.


    9. Packing:

    packing strictly as per the exporting standard or as per the customized request.


    10. Long-term quality warranty time:

    provide 12 months quality warranty time.
